1.1/2/3.2/4mm Low Iron/Csp Solar Mirror/AGC/High Reflective/93
Description
Basic Info.
| Model NO. | Solar Mirror |
| Finish | Silver |
| Usage | Solar Mirror |
| Customized | Customized |
| Work Time (H) | 25 Years |
| Type | Low Iron Float Glass |
| Technique | Coated Glass, Tempered Glass |
| Material | 1.1,2, 3.2mm,4mm,or 5mm Low Iron Float Glass |
| Packaging Details | Strong Wooden Crates with Interlayer Paper and Pl |
| Back Paint Color | White or Black |
| Product Name | Solar Mirror |
| Transport Package | Wooden Crates with Paper Interlayer |
| Trademark | tsing glass |
| Origin | China |
| HS Code | 70099100 |
| Production Capacity | 10000 Sqm/Day |
Packaging & Delivery
Package Size 10.00cm * 10.00cm * 0.50cm Package Gross Weight 0.250kgProduct Description
1.1/2/3.2/4mm Low Iron/Csp Solar Mirror/AGC/High Reflective/93-94%/Chemical/Chemically Tempered/Sliver//Linear Fresnel Flat/Bend/Bending/Parabolic Glass Mirror.Tsing Glass is a professional processed glass&mirror manufacturer and exporter in China.We can produce 1.1mm,2.0mm,3.2mm,4mm flat solar mirror ,solar concave mirror , bent solar mirror, parabolic trough reflectors, parabolic trough reflective mirrors. Product Description
Features:1)The raw material is the high quality low iron extra clear glass.2)Mirror Thickness:1.1mm,2.mm, 3mm, 3.2mm or 4mm.3)Silver coated with copper then 3 layers of special protective back paints
Flat Solar mirror
Original: Ultra white float glass (transmittance 94%)
Main specifications: the dimension can be cut as your need ,no edge process.
Thickness: 2mm ,3.2,4mm
Coating:silver coating.
Painting: three layersof protective paint,
UV resistant and external Boundary environment corrosion
Reflectivity: ≥ 92.5% (silver plated)
Parabolic Mirror Original:
Ultra white float glass (transmittance 93%)
Main specifications: opening 1.5M/2M/3M/6M
Thickness: 3mm~5mm
Plating:Silver plating
Aluminum plating Painting: three layers of protective paint, Anti UV and external environment corrosion Reflectivity: ≥ 93% (silver plated)
Dish Mirror & Linear Fresnel mirror
| Testing Content | Test Standard | Test Results |
| Focus ratio | Laser Facility Inspection | ≥99% |
| CASS testing | EN ISO9227(120h;Corrosion<1.5mm) | <200μ |
| SS testing | EN ISO9227(480h;Corrosion<1.0mm) | <50μ |
| Anti-Humidity testing | EN1036-1(40ºC,100%Hr;480h;Corrosion<0.2mm) | No corrosion found |
| Physical property | EN1036-1 | Paint Thickness>110μHardness>150 |
| Anti-UV testing | UVA340,60ºC;39W/SQM | Reflectivity loss<0.2% |
| Accelerated testing | Xenon arc lamp exposure 4500h | Reflectivity loss<0.2% |
| Anti-Abrade | ASTM D968 | <400g/μ |
Company advantage:1. Delivery on time.2. Considerable after-sale service.3. OEM Service/Customer design is welcome.4. Sample time is about 3-7 days.5. Size and thickness can be as requirements in commonly, that is flexible.6. Pass the international Certificate, CE, EN12150, ISO9001:2008, CCC, SGS, GB. SERVICE Our goal is not only to provide high quality glass, but also to maintain a personalized and professional relationship with each customer. No matter how big or small your requirement we will do our best to meet your demand. Our sales group has extensive glass expertise, as well as sound market knowledge and resources to help you make well-informed purchasing decisions. Furthermore, our sales professionals provide prompt "after sales service" and support to ensure a smooth glass purchasing experience. We can produce any size / shape /color Glass or mirrors according to your design.We will do our best to meet your demand. Please do not hesitate to contact with us if you have any questions.Looking forward to our cooperation!
